Casing Pipe and Tubing Pipe API-5CT Oilfield Service
Standard: API 5CT
OD: 48.26mm – 508mm
WT: 3mm – 35mm
Material: H40、J55、K55、M65、L80-1、N80-1、N80Q、C90、P110、Q125
Thread Type: LC, STC, BTC
Length Range: R1, R2, R3
Surface: External coating, varnish
Welcom to inquiry us for any product you are interested!
Shanghai ShengQiu offers a complete range of API 5CT steel casing and tubing pipe for kinds of demands in oil exploration and production. Material includes H40、J55、K55、M65、L80-1、N80-1、N80Q、C90、P110、Q125.
Steel Casing Pipe Appearance
Casing pipe section shape is round, in big diameter pipe and put it into the oil well, fixed by the cement, to protect other equipment which mostly made of iron and steel. Oil well shall be designed to bear the different strength of external power, as crush, explode, stress and chemical corruption. During the well drilling process, put casing into the well bore, it will stabilize the well bore perfectly.
API5CT casing pipe application
API 5CT casing pipe is used to support the oil and gas pipe wall, and to ensure the drilling process and the post-completion wells normal operation. Each well depending on the depth of drilling and geological conditions, to use several layers of casing. After cementing casing to be used to go down, it different from tubing, drill pipe and can not be reused, a one-time consumable materials. Therefore, the casing consumption accounts for over 70% of all the oil well pipe. According by usage can be divided into the sleeve pipe, surface casing, casing and production casing.
Our advantages
Shanghai ShengQiu is working on providing high quality casing pipe with most competitive price. Especially for the the grades J55/K55, N80-1 and N80Q casing. Moreover, Octal is engaged in providing various premium connection casing pipe, for the server working conditions.
